POD and FloPro Air Regulator (ARG30-N02G2H-Z-B-X406) with Pressure Gauge and Set Nut
The POD and FloPro Air Regulator is an essential pneumatic component for ensuring precise and consistent air pressure delivery to critical systems in the car wash, including the Detergent PODs, Maintenance PODs, and FloPro detergent units.
This regulator, equivalent to the SMC ARG30 series, features a robust modular design with a 3/8" body size and 1/4" NPT ports. A key benefit is the inclusion of a built-in pressure gauge mounted at a 90-degree angle, allowing for easy monitoring of the 0-100 PSI regulating pressure range. A set nut secures the desired pressure setting.
Engineered for reliable function, it includes a backflow mechanism that allows reliable air pressure discharge from the outlet side back to the inlet side when needed. With a maximum operating pressure of 1.0 MPa (approx. 145 PSI), this regulator is built for durability and performance in the demanding wash environment.
- Equivalent Model: ARG30-N02G2H-Z-B-X406
- Product Type: Pneumatic Air Regulator
- Body Size: 3/8"
- Port Size: 1/4" NPT
- Pressure Gauge Range: 0–100 PSI
- Pressure Gauge Mounting: 90 Degrees (Built-in)
- Max Operating Pressure: 1.0 MPa (Approx. 145 PSI)
- Proof Pressure: 1.5 MPa (Approx. 217 PSI)
- Regulating Pressure Range: 0–100 PSI
- Operating Temp. Range: 23F – 140F
- Key Features: Modular design, Set Nut, Backflow Mechanism
- Application: Detergent PODs, Maintenance PODs, and FloPro units.
- Precise Control: Allows for accurate regulation of air pressure in the 0–100 PSI range.
- Integrated Monitoring: Includes a built-in, 90-degree mounted pressure gauge for easy visual inspection.
- Backflow Mechanism: Enables reliable discharge of air pressure from the outlet to the inlet.
- Wide Application: Essential for pneumatic control across critical wash systems (PODs and FloPro).
